Compact package metallized film resonance capacitor designed to handle large voltages and currents

Short Description:

1. Small compact package size

2. Capable to hanlde large voltages and currents

3. Use low loss dielectric of polypropylene film

Send email to us Download as PDF

Product Detail

Product Tags

RKMJ-PS series

RKMJ-PS series designed to handle large voltages and currents, Widely used Magnetizer Demagnetizer, laser power, medical equipment, energy storage welding machine. Such as DC high voltage equipment, high voltage power converter, rectifier filter device oscillation circuit, continuous pulse device, impulse voltage generator, the impact of current generator, impact divider and other non-continuous pulse device.

Specification

Rated capacitance	0.1uF
Rated voltage	40KV
Non-recurrent surge voltage	52KV
Maximum current	30A
Voltage Rise Time	5000v/µs
Maximum peak current	500A
Maximum surge current	1500A
Tangent of the loss	0.0002 (1KHz)
Discharge resistance	30000MΩ
Self inductance	≤50nH
Operating temperature	-40℃~ +85℃
Flame retardation	UL94V-0
Service life	100000H
Reference standard	IEC 61071
